Potting Equipment Heating 3 Axis Automatic Glue Dispenser 200x200x100mm Working Area

Type : Gluing Machine

Applicable Industries : Manufacturing Plant

Showroom Location : Turkey, Italy, Viet Nam, Indonesia, Russia, Malaysia

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Warranty of core components : 1 Year

Core Components : PLC, Engine, Bearing, Gearbox, Motor, Gear, Pump

Condition : New

Application : Machinery & Hardware

Packaging Type : case

Packaging Material : Plastic, Wood

Automatic Grade : Automatic

Driven Type : Electric

Voltage : Customized

Place of Origin : Guangdong, China

Brand Name : D&H

Weight : 500 KG

Warranty : 1 Year

Key Selling Points : high precision

Product name : adhesive dispenser

Function : AB epoxy mixing&stirring

speed : 0-200mm/s

metering precision : ±2%

Tank Capacity : 10L,25L,40L,60L,customized

Glue type : two component

heating : available

self-cleaning : available

Mixing ratio : 1:1--10:1 adjustable

working area : 200x200x100mm

Price : $25,000.00/pieces 1-1 pieces

Contact Now

Product Overview

cnc 3 axis automatic glue dispenser auto epoxy machine potting equipment

I Machine demand description

Electronics are increasingly present in our lives,these technologies all use a wide array
of components – sensors, actuators, central processing units (CPUs), printed circuit boards (PCB), etc. – that need to be protected against environmental factors such as dust and moisture, as well as fluids and heat and fire exposure. Our 2 component application equipment is the the good machine for potting and encapsulating vary parts and products, which apply different production processes required metering , mixing , dosing , dispensing and potting with high accuracy and high efficiency .

II Metering working Principle
The machine will have two tanks for keeping Liquid A & B separately.
There are two sets of metering pumps inside the machine, draining out liquids individually from tank A & B. Liquid A & B mix with
each other in the mixer pipe and dispensed out according to the programmable data .

III Features and Benefits:
1. The glue potting system are for AB component materials for metering, mixing and potting .
2. Accurated metering and evenly mixing helps to avoid possible waste of glue.
3. Dispensing size and positioning keep consistently and fastly.
4. Good universality makes our machine suitable for applications of LED, electric and others glue potting and dispensing needed.
5. Easy to program and operate.
6.Fast metering & mixing and running speed keep potting with high efficiency.
7. Tally function, non-standard mode, tank level alert, filter mode, liquid display device, preventing backflow device and other functional device.

IV Machine functions：
* Mixing ratio ：100:100-100:10 adjustable . Dynamic or static mixing mode are optional .
* Tank liquid level sensor ：Tank liquid level alarm helps remind glue level line in tank and supplement materials immediately.
* Vacuum filling：The machine can automatically feeding material by using of the negative pressure of AB vacuum tank .
* Vacuum degas：Vacuum defoaming can remove the bubbles contained in the material,and this degas system can satisfy different fluid mixing and potting .
* Heating：Heating helps glue, especially PU and epoxy, to quickly reduce viscosity in cold weather, increase flow speed, and improve glue filling efficiency.
* Self-cleaning ：Automatic cleaning can quickly clean the mixing tube and prevent the mixture from solidifying
* Self-discharging：Automatic discharging can discharge the mixture that is about to be solidified in time to prevent the mixture from solidifying in the mixing tube.

Potting Equipment Heating 3 Axis Automatic Glue Dispenser 200x200x100mm Working Area

Application：

Auto parts , Reverse Sensor, Electronic Circuit Board, Electronic Ballast，air Filters, LED products ,Electronic components,Crafts，Ads modules, Capacitors, Power supply, Transformer, end cap for filter, solar junction box,Power module,Ignition coil, Sensor, Photovoltaic module, Photovoltaic inverter and so on .

FEATURES AT A GLANCE

Front elevation

down elevation

side elevation

PRODUCT CONFIGURATION

ITEM	Parameter
Mixing ratio	1:1--10:1 adjustable
Working range	200200100mm
Displacement speed	200mm/s（speed）
Out-glue speed	1-12g/s
Accuracy	±2%（output volume）±2%（mixing）
tolerance	≤0.2mm
Flow control	Digital input
Program memory	99pcs
Motion trail	Dot , line ,curve ,circle
Automatic controlling system	Touch screen (to achieve program programming, modification, storage and so on
Out-glue control system	AB glue back suction valve, achieve AB glue independent operation
Programmatically	Tech programming With computer systems (Micro software Windows 7,Windows10 optional)
Mixing method	dynamic mixing
Power supply	220V/50Hz/1500W
Air source	0.5-0.8Mpa
Viscosity range	50-20000cps
Outer dimension	1500L1200W1600H mm
A tank	25L stainless tank（optional）
B tank	10L stainless tank（optional）
Others	AB tank 、A pump、AB pipeline heating function

Successful Project

marketing activities oversea

Project in India

Project in Russia

Suitable materials ：

Two component silicones ,polyurethane,epoxies,two part compound,AB compound,Bi-compound
other potting dispensing adhesive .
